Ohaus Explorer EXR 10201 Precision Balance
- Maximum Capacity: 10,200 g
- Readability: 0.1 g
- Pan Size: 7.9 in x 7 in (201 mm x 178 mm)
- Internal Calibration: AutoCal™ automatic
- Item Number: 31059236
OHAUS Explorer EXR10201 Precision Balance
Best for larger samples, containers and production checks where fast, dependable tenth-gram resolution is appropriate.
The OHAUS Explorer EXR10201 precision balance provides a 10,200 g capacity and 0.1 g readability for dependable laboratory, production and quality-control weighing.
The new Explorer EXR platform is designed around reliable weighing performance, a simplified user experience and flexible communication. A digital high-speed load cell, AutoCal internal calibration, digital leveling and two programmable touchless sensors help operators work efficiently while reducing avoidable handling errors.
Key Advantages
The modern 7-inch glass touchscreen makes applications and stored sample libraries easy to access. Four-level user management, an internal system log with capacity for up to 100,000 entries and time synchronization support help laboratories strengthen data traceability and controlled workflows.
USB Host (Type A) x 2, USB Device (Type C), Ethernet and RS232; optional Wi-Fi and Bluetooth dongle. Driverless HID support can send weighing data directly to compatible computer applications or keyboards.
The open stainless-steel platform provides convenient access for larger vessels, containers and production samples.
This model is intended for laboratory and industrial measurement and is not designated as legal for trade.
Applications
Basic weighing, parts counting, check counting, percent weighing, check weighing, dynamic weighing, totalization, formulation, differential weighing, density determination and peak hold.
Display
7-inch TFT colour touchscreen with glass overlay
Operation
AC adapter input: 100-240 VAC, 0.5 A, 50-60 Hz; output: 12 VDC, 1.5 A
Communication
USB Host (Type A) x 2, USB Device (Type C), Ethernet and RS232; optional Wi-Fi and Bluetooth dongle
Construction
Metal housing, stainless-steel weighing pan, two programmable touchless sensors and terminal status light. Draftshield models use anti-static glass around the weighing chamber.
Design Features
AutoCal automatic internal calibration, digital level indication, driverless HID connection, four user-access levels, 100,000-entry system log, time synchronization and storage for up to 1,000 application sample libraries.
| Model | EXR10201 |
| Item Number | 31059236 |
| Maximum Capacity | 10,200 g |
| Readability | 0.1 g |
| Pan Size | 7.9 in x 7 in (201 mm x 178 mm) |
| Internal Calibration | AutoCal™ - Automatic |
| Draftshield | Not included |
| Dimensions | 15.5 in x 3.8 in x 9 in (393 mm x 96 mm x 230 mm) |
| Display | 7-inch colour TFT touchscreen |
| Legal for Trade | No |
| Power | AC adapter included |
| Communication | USB, RS232 and Ethernet; optional Wi-Fi/Bluetooth |
Q&A
What capacity and readability does the OHAUS EXR10201 provide?
The EXR10201 has a maximum capacity of 10,200 g and a readability of 0.1 g.
Does the EXR10201 calibrate automatically?
Yes. AutoCal™ automatic internal calibration helps maintain accurate performance when temperature or operating conditions change.
Which weighing applications are built into this balance?
Its applications include basic weighing, parts counting, check weighing and counting, percent weighing, dynamic weighing, totalization, formulation, differential weighing, density determination and peak hold.
How can weighing data be transferred?
The balance includes USB host, USB device, Ethernet and RS232 interfaces. Optional Wi-Fi and Bluetooth connectivity are available through a compatible dongle.
Is the OHAUS EXR10201 legal for trade?
No. This version is intended for laboratory, research, quality-control and industrial measurement rather than commercial transactions based on weight.
